PCB assembly for brain stereotaxic instrument

The brain stereotactic instrument uses three-dimensional coordinate system utilizedsigns or other reference points outside the skull to determine the location of certain neural structures under the cortex for directional stimulation, destruction, and drugsinjection, guiding potentials etc under non-direct vision exposure.

The brain stereotactic instrument can play important rolesin the fields of neuroanatomy, neurophysiology, neuropharmacology and neurosurgery, and can be used for directional injection, stimulation, destruction, and guiding potential of nerve structures.

Performance indicator:

1,Material: alloy material, double operating arm

2, Size: 350 × 250 × 340mm

3,The operating arm rotates 360 degrees, and the swing amplitude is 180 (-90°~90°).

4, Counting accuracy: ± 0.1mm

5, The accuracy of the present thruster: ± 0. 1mm

6,Three-dimensional propulsion stroke: 80mm (X-axis: 80mm, Y-axis 80mm, Z-axis 80mm)

7,Scale laser engraving

8, Weight: 5.5kg

9, Standard rat adapter 1 pair (including ear rod)

In the production and assembly of brain stereotaxic instrument, FASTPCBA greatly reduces the production cost and maintenance cost on the basis of ensuring the original performance of the product, and provides more support for a series of medical devices.
