PCB for automotive LED headlights A10

Product application: headlights, fog lights, license plate lights, reversing lights, brake lights, turn signals, position lights, position lights, parking lights and warning lights and daytime running lights.

Aluminum substrate: MCPCB 6061

Board thickness: 1.6MM

Copper thickness: 2OZ

Surface treatment: black oil and white letters, heavy gold, holes and substrate conduction

single board area: 201MM diameter circle

Advantages:

First, energy saving: It is directly converted from electric energy to light energy by light-emitting diodes. Compared with ordinary car bulbs, it consumes only 1/10 of the power of traditional lamps, which can save fuel consumption and protect automobile circuits from excessive load currentburning.

Second, environmental protection: no ultraviolet and infrared rays in the spectrum, low calorific value, no radiation, small glare, and waste can be recycled, no pollution, no mercury, can be safely touched, is a typical green lighting light led source.

Third, long life: there is no loose part in the lamp body, there are no shortcomings such as filament light-emittingeasily burning, heat deposition, light decay, etc. Under the proper current and voltage, the service life can reach 80-100,000 hours, which is longer than the traditional light sourceeven more than 10 times longer. (with one replacement, lifelong use features

Fourth, high brightness, high temperature resistance. (Electrical energy is directly converted into light energy, the heat is small, it can be touched by hand, safe and secure)

Fifth, small size. Can change the lamp mode optionally, so that the car modelling can be diversified. Automotive manufacturers favorable LEDs, which are entirely determined by the advantages of LEDs themselves.

Sixth, good stability, led strong seismic performance: resin packaging, not easy to break, easy to store and transport.

Seventh, the light purity is high, the color is clear and vivid, no need to filter the light filter, the light wave error is within 10 nanometers.

Eighth, the reaction speed is fast, no need for hot start time, it can be illuminated within microseconds, the traditional glass bulb has a delay of 0.3 seconds, which can prevent rear-end collision and ensure safe driving.

About us:FASTPCBA have specialized in PCB&PCBA field for 15 years,with energetic marketing dep, strong engineering,skillful technician,professional QA and QC group,superior after-sale service.

Company Information:

Our aggressive business strategy enables us to deliver high competitive services for our diverse, competitive customer base. Through this strategy, we are able to make fast, flexible decisions in response to changing market conditions and create most value and benefits for customers.

As for Service, we provide 7days 24hours on-line professional Pre-sale, Selling and After-Sale service to solve any question about the order. Any time, any requirement will get Prompt Reply from our well-trained and friendly support staff.Wireless rear view system

Our main market is Europe, north USA,Australia, South America, and Asia. we will put much more effort to build connection with more customers in more area. All we want to do, is to connect the world by our products, to share the Value, Happiness and Achievement with more customers.Wireless rear view system

FASTPCBAhas extensive board assembly capability including:

• Automated and manual fine pitch SMT.
• Multi-layer printed circuit boards, flex boards
• BGA with x-ray and rework capability.
• Lead-free Assembly
• Wave soldering.
• In circuit testing.
• Functional testing.
• Conformal coating.
• Burn in.
• In-line AOI inspection system
• XRAY Inspection AOI Test
• 1 piece and small batch builds.
•


• Certificates:

  All of our PCB and PCBA areISO,TS approved.

  Quality Guarantee is the basis of our clients’ trust.




•


• Our chairman Luoxinhua pay much attention on exhibition,,that we have taken part in many exhibitionsbothatdomestic andabroad.


•

• Application case in automotive area


•




• Without MOQ limits,deliver order fast.

•

•


  FAQ




  Q1:What service do your94v0 circuit board factory have ?

  FASTPCBA: We provide turnkey solution including Fr4 pcb fabrication, SMT, plastic injection & metal, final assembly,testing and other value-added service.







  Q2:What are the main products of your pcb production?

  FASTPCBA: Our Fr4 pcb services are mainly for the industries including Medical,Automotive,Communication.







  Q3:Is FASTPCBA a factory or trade company?

  FASTPCBA: FASTPCBA is a factory with electronic circuit board factory located in China










  Q4:Do you have any minimum order quantity (MOQ) requirement for automotive PCB assembly?

  FASTPCBA: No, we do not have MOQ requirement, we can support your projects starting from prototypes to mass productions.




  Q5:How is your production capacity?

  A:We have 3 SMT lines,take line A as examples,it can produce 79000 resolutionper hour.We also have one line wave-soldering and two manual soldering lines.

  94v0 circuit board factory and automotive electronic component sourcing
