Smart electronic board for wired switch panel

Supplier Type:

customized

Place of Origin:

Guangdong, China

Base Material:

high frequency, alum

Copper Thickness:

0.30z-30z

Min. Hole Size:

0.1mm

Min. Line Width/Spacing:

3mil

Surface Finishing:

HASL, OSP, Immersion Gold

Testing Service:

IPC-600 II

Certificate:

ISO9001

MOQ:

1pcs

Wired self-reset switch panel with a variety of appearances. Has the following characteristics:

With status feedback indicator

Indicator voltage: DC12V

Indicator polarity: commonpositiveor commonnegative

Customizable button names and LOGO

Support 2, 3, 4, 5 joint panels

LED indicator voltage: DC12V

K1--K6: Push button switch

KC: button switch common line

D6--D1: LED indicator line

DC: LED indicator public line

Customizable switch panel styles are available
