Smart electronic board for wired flame sensor

Place of Origin:

Guangdong, China

Brand Name:

FASTPCBA

Copper Thickness:

1OZ

Board Thickness:

2mm

Min. Hole Size:

0.1mm, 0.16mm

Min. Line Width:

3mil

Min. Line Spacing:

3mil

Surface Finishing:

OSP

Base material:

high frequency, alum

Min. Line Width/Spacing:

3mil

Certificate:

ISO9001

Smart electronic board for sensor characteristics:

1,It can detect flame or light sourceforwavelength in the range of 760 nm to 1100 nm. The flame distance is 80 cmforthe lighter. The larger the flame, the farther the test distance is.

2, the detection angle is about 60 degrees, especially sensitive to the flame spectrum

3, the sensitivity is adjustable

4, the comparator output directly triggers the relay

5, the external dimensions are: 50x26mm, thickness 19mm, with fixed bolt holes for easyinstallation

6, it’s convenient to connect wire due to the output has a blue terminal block.
